Thawv Trailer
3 Axles shipping Thawv trailer siv rau lub thawv thauj khoom.
Lub luag haujlwm hnyav thiab tsim kom muaj zog ntxiv; Opting rau siab zog Q345B steel; Kuv beam welded los ntawm automotive arc-submerge txheej txheem.
Siv 100 feem pua ntawm cov khoom lag luam nto moo rau peb 3 axles shipping thawv trailer!
Khoom Taw qhia
Tare luj | Txog 6.5 tons |
Sab nraud dimension (mm) | 12450*2490*1400 |
Loading peev (Ton) | Tsawg dua lossis sib npaug rau 45T (40FT) |
Axles | 3 axles square qag nrog 13 tons peev, FUHUA hom (Tuam Tshoj hom zoo tshaj) |
Lub log | 12.00R22.5 los yog 315/80R22.5 |
Rim | 9.00-22.5 Tuam Tshoj Hom |
Kev ncua | Lub luag haujlwm hnyav tri-axle nrog 13 tons peev, FUHUA hom |
Nplooj nplooj | 90 (W) hli * 13 (Thickness) hli 10 pcs nplooj hlav |
King pin | JOST hom 2.0 lossis 3.5 |
tsaws ob txhais ceg | JOST hom E100 lossis Tuam Tshoj hom 28 Tuj (ob zaug ceev) |
Main Beam | Qhov siab: 500mm, sab phaj yog 14 hli, nruab nrab phaj yog 8 hli, nqes phaj yog 16 hli; Khoom siv yog Q345B Steel. |
Nres chamber | WABCO relay valve |
Twist Locks | 12 units ISO twist xauv |
ABS | xaiv tau |
Teeb | LED teeb |
Qhov hluav taws xob | 24V |
Hluav taws xob | Ib chav ntawm 27V 7-pin ISO 1185 socket |
Tool lub thawv | Ib thooj, 1m * 0.5m * 0.5m (Qhov loj tuaj yeem xaiv tau dawb) |
Kev pleev xim | Xuab zeb blasting ua ntej painting; ib tug cam khwb cia ntawm primer, anti-corrosion; ob lub tsho ntawm tiav painting; xim qhia los ntawm cov neeg siv khoom. |
3-Axle 40FT 60t thawv Trailer nrog Strong Structure Chassis Trailer Ua los ntawm High-Strength Steel Siv rau Thawv Thauj.Skeleton thawv trailer yog siv los thauj cov thawv, thiab nyob ntawm seb lawv hom, lawv tsim nyog rau nqa 20FT ntim thiab/ los yog 40FT thawv. Tag nrho cov qauv ntawm lub thawv trailer yog ncaj nqaj los yog gooseneck, nws yog tsuas yog siv nyob rau hauv lub logistics systems ntawm ships, ports, txoj kev, txoj kev loj, chaw nres tsheb, txuas hniav, tunnels thiab multimodal thauj.
Yog tias koj muaj kev xav tau tshwj xeeb rau lub thawv trailer nrog lub gooseneck, peb tuaj yeem tsim nws rau koj raws li koj xav tau.
Tongya Automobile Co., Ltd tau tsim nyob rau xyoo 1982, peb yog thawj lub chaw tsim khoom ntawm cov tsheb thauj khoom hauv peb lub zos. Peb muaj peb tus kheej hom: TONGYADA.
Peb cov khoom yog roj tank semi trailer, kua bitumen tanker, bulk cement tank semi trailer, tsis tshua muaj txaj semi trailer, flatbed semi-trailers, thawv trailer, dump semi trailer thiab lwm yam.Lub ntsiab beam rau lub thawv trailer yog hnyav luag hauj lwm thiab ntxiv durability tsim. , siv Q345B steel.
Vuam los ntawm cov txheej txheem Submerged-Arc tsis siv neeg, pleev xim rau hauv 21m zoo xim pleev xim thiab pleev xim rau chav tsev, xuab zeb blasting ua ntej pleev xim, ib lub tsho tiv no ntawm primer, tiv thaiv corrosion, ob lub tsho loj ntawm cov xim tiav.
Muaj ob txoj hauv kev rau lub thawv trailer shipping
A, Ob chav nyob tiaj tus txaj semi trailer muab tso rau hauv ib lub thawv 40HC, qhov trailer txuas los ntawm bolts nrog lub cev trailer, ua li no, peb tuaj yeem txuag tau ntau tus nqi thauj khoom.
B, Shipping los ntawm bulk cargo nkoj los yog yob-on-roll-off nkoj, peb trailers pawg ua ke kom txo tau tag nrho cov loj.
Txais tos rau peb lub Hoobkas txhua lub sijhawm!
