20ft Semi Trailer
Daim ntawv thov ntawm 3 Axles 20ft semi trailer
20ft semi trailer trailer tuaj yeem siv los thauj cov qauv loj ntawm cov thawv hauv cov chaw nres nkoj lossis los ntawm qhov chaw mus rau qhov chaw ntawm txoj kev. Haum rau lub tuam txhab logistic, davhlau ya nyob twg chaw nres nkoj, kab xa khoom, xa mus, chaw tsim khoom tsheb thauj khoom.
Khoom Taw qhia
Txheej txheem cej luam ntawm 20ft semi trailer Scientific tsim nrog advanced computer-aided tsim software, finite caij tsom xam ntawm tus ncej raws li lub tsheb thauj khoom zoo
Welded tsis siv neeg submerged-arc txheej txheem. Ua kom tiav chassis tua blasting los ntxuav xeb.
Superior zoo thiab nto moo hom peb siv ntawm cov khoom sib txawv trailer. Cov ntsiab lus tau piav qhia raws li hauv qab no.
Technical Parameters | |
Tare luj | Txog 6000kg |
Loj | 7300mm × 2500mm × 1550mm |
Them nyiaj | 25T |
Main beam | Sab saum toj flange 14mm, dav 140mm; Middle Flange 8mm siab 500mm; hauv qab flange16mm, dav 140mm |
Sab beam | 16 # channel steel (Q235) |
Cross tus tswv cuab | 10 # channel steel (Q235) |
Pem teb | 3mm Flat Phaj |
Qag | 3 qag 13T (Original FUWA hom) |
tsaws iav | Ob-ceev, phau ntawv khiav hauj lwm, hnyav tsaws iav 28T |
Kev ncua | Mechanical suspension |
Nplooj caij nplooj ntoos hlav | Nplooj caij nplooj ntoos hlav 6sets, 10pcs, 90 × 13 mm |
Lub log | 12 R22.5, 12 pcs |
Lub log rim | 9. 0-22.5, 12pcs |
Kingpin | 3.5 "bolt-hauv huab tais tus pin |
Twist xauv | 8 pcs ib |
Braking system | WABCO RE6 relay valve; T30/30 caij nplooj ntoos hlav nres chamber; 40L cua tso tsheb hlau luam |
Teeb | LED 8 sab teeb thiab 2 rear teeb 2 dav teeb |
Kev pleev xim | Ua kom tiav chassis xuab zeb blasting los ntxuav xeb, 1coat ntawm anticorrosive prime, 2coats ntawm zaum kawg xim |
Cov khoom siv | Ib lub thawv khoom; ib lub log tsheb spare; ib lub crank; ib lub taub hau taub hau; plaub sab teeb; ob lub teeb tom qab |
Qhov zoo ntawm 3 Axles 20ft semi trailer
①Mature technology, tuaj yeem tsim muaj ntau ntawm cov nqi sib tw
② Lub teeb yuag nrog lub zog siab los thauj cov thawv
③Shipped ob lub thawv, los yog RORO, bulk shipping
④ Zoo nkauj thiab ntxim nyiam nrog peb kev ua haujlwm zoo
⑤ Cov lus teb ceev ceev thiab hloov tau yooj yim los ntawm peb pab neeg ua haujlwm Qhov chaw sib txawv kom tau txais kev txhawb nqa tag nrho ntawm kev xa khoom thiab kev tsim khoom
⑥Ultraton lub sij hawm ntev tenet los ua koj tus khub txhim khu kev qha coj koj Tus nqi Ntau dua ua rau koj txhawj xeeb txog kev pab cuam tom qab muag.
Cim npe nrov: 20ft semi trailer, Suav teb, neeg muab khoom, manufacturers, customized, nqe
