Tuam Tshoj Manufacturing TONGYA 3 Axles Tsheb Tipper Semi Trailer
1.3axles rear tipper semi trailer yog ib hom tshiab ntawm semi-trailer pob tseg tsheb tsim los ntawm peb lub tuam txhab. 2.Lub 3axles rear tipper semi trailer muaj qis dua qhov hnyav thiab yooj yim nqa thiab muaj kev nyab xeeb dua, tsis yooj yim rau dov. Lub thav duab thiab lub tsheb thauj khoom tau txais daim ntawv pov thawj hauv tebchaws thiab nws yog qhov tsim nyog rau kev thauj mus los ntawm cov khoom loj thiab cov khoom tawg, xws li cov thee, ore, av, thiab cov khoom siv.
Khoom Taw qhia
Tuam Tshoj Manufacturing TONGYA 3 axles rear tipper semi trailer
1.Cov qauv ntawm 3axles rear tipper semi trailer: nws suav nrog lub thawv trailer lub cev, txav hauv qab phaj, guardrail phaj, wedge block, wedge block seat, lifting cylinder, piston pas nrig, tig qhov chaw, thiab movable hauv qab phaj hauv qab lub thawv lub cev. .
2.Qhov kom zoo dua ntawm 3axles rear tipper semi trailer: lub thav duab tsim ntawm lub trailer yog tsim nyog, thiab cov craftsmanship yog siab heev. Lub thawv lub cev yog ua los ntawm lub zog muaj zog txias-kuav los tiag corrugated steel phaj, tsis muaj lub cev pob txha, thiab qhov siab ntawm lub thawv lub cev yog sib txawv thiab qhov chaw thauj khoom loj.
3.Qhov kev ua haujlwm ntawm 3axles rear tipper semi trailer: Txij li thaum lub thawv ntim khoom tuaj yeem hloov kho lub kaum ntse ntse rau kev tshem tawm, nws txuag lub sijhawm thauj khoom thiab ua haujlwm, ua kom lub voj voog tsheb thauj mus los, txhim kho kev tsim khoom, thiab txo nqi tsheb thauj mus los. Nws yog ib lub tsheb tshwj xeeb uas siv rau kev thauj mus los.
Tuam Tshoj Manufacturing TONGYA 3 axles rear tipper semi trailer
KhoomSpecifications:
|
3axles rear tipper semi trailer Specification |
|
|
Khoom npe |
Tsheb Semi Trailer |
|
Khoom siv |
Q345B carbon hlau |
|
Xim |
Cov neeg siv khoom xaiv tau |
|
Kev siv |
Thauj Khoom Thauj Khoom, Thauj Pob Zeb, Pob Zeb |
|
Main Beam |
Q345B carbon steel "H" nqaj |
|
Lifting System |
HYVA Brand |
|
Chaw thau khoom muaj peev xwm |
80 ton |
|
Tare luj |
10 ton |
|
Kev pleev xim |
Xuab zeb Blasting, Anti corrosive Prime |
|
Dimension |
9500x2500x3700mm |
|
Pem teb |
6mm Checkered Phaj |
|
Teeb pom kev zoo |
LED Teeb |
|
Kev ncua |
Mechanical Suspension |
|
Qag |
20Ton Fuwa/BPW |
|
Lub log |
12R20 |
|
tsaws iav |
Standard 28Ton |
|
King pin |
3.5 "(90mm) |
|
Nres System |
Dual Line Braking System |
|
Rim |
8.0-20 |
|
Nplooj Caij nplooj ntoos hlav |
90 (W) mm * 16 (Thickness) mm * 10 (txheej) |
Cov ncauj lus kom ntxaws ntawm Tuam Tshoj Manudacture TONGYA 3 axles rear tipper semi trailer:
Cim npe nrov: Tuam Tshoj Manufacturing Tongya 3 axles rear tipper semi trailer, Tuam Tshoj Tuam Tshoj manufactory tongya 3 axles rear tipper semi trailer manufacturers, lwm tus neeg
