Poob Sab Trailer
1, Peb qhov poob sab trailer siv cov hlau tshiab, yog qhov zoo thiab siv dav.
2, Kev poob sab trailer raug xa tawm mus rau Africa thiab Southeast Asia txhua xyoo puag ncig, thiab tau txais txiaj ntsig zoo los ntawm cov neeg siv khoom hauv zos.
3, Peb qhov poob sab trailer yog hnyav thiab lub teeb kom nqa ntau cov khoom thauj.
4, Peb muaj 20 xyoo ntawm kev paub txog exporting poob sab trailer thiab muaj kev nkag siab tob txog kev lag luam hauv zos
Khoom Taw qhia
Qhov hnyav tag nrho | Txog 6,8 tons |
Sab nraud dimension (mm) | 13000 × 2500 × 2850mm |
Loading peev (Ton) | 50T |
AXLES | 13T, 3 qag FUWA Hom, |
Lub log | 12.00R22.5, 13pieces Daim duab peb sab lossis ob lub npib hom |
Rim | 9.00-22.5, 13pieces Tuam Tshoj Hom |
Kev ncua | Mechanical suspension (America Hom) |
Nplooj nplooj | 90 (W) hli * 13 (Thickness) hli * 10pcs, hnyav hnyav hom |
King pin | JOST hom 2.0 lossis 3.5 nti bolts hom |
Txhawb ceg | 28T los yog JOST hom |
Main Beam | Qhov siab: 500mm, phaj siab yog 14mm, nruab nrab phaj yog 8mm, |
Platform | 3mm pob zeb diamond phaj steel |
Sab beam | 16 # channel steel |
Nres chamber | WABCO RE 6 relay valve; T30/30 ntxiv rau T30 Caij nplooj ntoos hlav nres chamber; Ib daim ntawm 45L cua tank |
Hooks | Nrog |
Twist Locks | 12 daim (Lifting hom) |
Valve | WABCO valve |
ABS | Nrog |
Teeb | LED teeb |
Qhov hluav taws xob | 24V |
Txais | 7 txoj kev (7 hlau hlua) |
Tool lub thawv | Ib thooj, 1m × 0.5m × 0.5m (Qhov Loj tuaj yeem xaiv tau dawb) (nrog 1 unit Tyre spanner, 1 unit gudgeon tes tsho thiab 1 unit cranking |
Kev pleev xim | Ua kom tiav Chassis xuab zeb blasting los ntxuav xeb, 1 lub tsho tiv no ntawm anticorrosive prime, 2 lub tsho tiv no ntawm cov xim kawg |
Cov ntsiab lus shipping | Thauj los ntawm RORO lossis 45FT thawv. |
Qhov poob sab trailer siv los thauj khoom ntau yam khoom thiab cov khoom siv, xws li xuab zeb, hnab, nqaij qaib thiab lwm yam. Tsis tas li ntawd, qhov poob sab trailer, dav siv hauv kev lag luam tsheb thauj mus los. Haum rau nruab nrab / ntev kev thauj mus los ntawm nruab nrab / hnyav hnyav thiab cov khoom thauj ntau. Lub siab sab cargo trailer tuaj yeem ntxiv nrog lub thawv tig xauv kom thauj lub thawv.
3 qag poob sab trailer, nplej trailer thiab sidewall kos bar trailer. Thiab lub peev xwm thauj khoom muaj 30/40/60/80/100 tons rau koj xaiv. Customizable sab phab ntsa qhov siab.
Cov poob sab trailer yog customized raws li nws xav tau, nrog rau configuration, tsim, painting, thiab lwm yam.Nws khaws ib tug nrov tshaj plaws 3 qag poob sab trailer, nws payload yog 60 tons. Qhov no yog qhov feem ntau siv thiab classic style.Tsis ntev los no, peb tau txais kev tawm tswv yim los ntawm peb cov neeg siv khoom thiab tsis muaj qhov tsis ntseeg tias cov neeg siv khoom txaus siab rau peb cov semi trailer. Qhov tseem ceeb tshaj plaws, nws txaus siab los qhia nws cov phooj ywg zoo kom xaj thiab yuav semi trailer los ntawm peb.
Cim npe nrov: poob sab trailer, Suav teb, neeg muab khoom, manufacturers, customized, nqe
