High Quality Curtain Semi Trailer
Kab hlau rhuav semi-trailer uas tuaj yeem qhib los ntawm txhua sab, sab kab hlau rhuav semi-trailer tuaj yeem yooj yim thauj khoom thiab thauj khoom ntawm sab laug, sab xis, nraub qaum, thiab sab saum toj. Nws ua qhov zoo tshaj plaws hauv rau lub tsheb thauj mus los, suav nrog kev thauj mus los ntau yam, khoom siv hauv tsev, dej haus, ntawv yob, khoom siv tsheb, vaj huam sib luag, thiab cov khoom ntim khoom.
Khoom Taw qhia
High Quality Curtain Semi Trailer
Specifications:
|
Khoom |
Kab hlau rhuav semi trailer |
|||
|
Tare luj |
Txog 7000KG |
|||
|
Dimension sab nraud dimension |
Ntev: 16900mm |
Dimension |
Ntev: 16660mm |
|
|
Dav: 2550mm |
Dav: 2480mm |
|||
|
Qhov siab: 4000mm |
Qhov siab: 2690mm |
|||
|
Upper qauv Assembly |
Ntaub |
Sab saum toj ceev |
900g±50g/㎡ |
|
|
Sab ntom ntom |
Ntau dua lossis sib npaug li 680g / ㎡ |
|||
|
Lub nro locking mechanism nyob rau hauv qab yog ua los ntawm stainless hlau |
||||
|
pem teb board |
Khoom siv |
Plywood |
||
|
Thickness |
30 hli |
|||
|
Ncej |
Kem |
Muaj 4 kab ntawm txhua sab (8 kab hauv tag nrho trailer) |
||
|
Baffle |
Muaj 4 tshem tau aluminium Baffles nruab nrab ntawm kab (20 ntawm txhua sab) |
|||
|
Rov qab qhov rooj |
Ob lub qhov rooj txhuas nrog 4 lub qhov zais zais (2 lub tshuab hauv ib lub qhov rooj), nrog rau cov khoom siv xauv xauv tau nruab rau sab nraud hauv pem teb kom ruaj ntseg lub qhov rooj hauv qhov qhib. |
|||
|
Sab loading qhov siab |
2600 hli |
|||
|
Khiav mechanism |
Qag |
Hom |
SAF |
|
|
Hom |
3 qag (thawj qag nqa) |
|||
|
Tus lej |
3 |
|||
|
tonnage |
10T |
|||
|
Rim |
Hom |
11.75*22.5 |
||
|
Lub log |
Hom 品牌 |
Daim duab peb sab hom 3角牌 |
||
|
Hom |
385/65R22.5 |
|||
|
Tus lej |
7pcs (nrog rau 1 lub log tsheb seem) |
|||
|
Kev ncua |
Cua ncua kev kawm ntawv, tag nrho cov trailer tuaj yeem nqa tau |
|||
|
Khoom siv |
King pin |
Hom |
JOST hom |
|
|
Txoj kab uas hla |
2 0 nti |
|||
|
tsaws iav |
SAF hom |
|||
|
Spare log tsheb |
1set ib |
|||
|
Nres system |
Nres chamber |
4 ob chav nres chamber thiab 2 tib chamber |
||
|
EBS |
WABCO 4S/2M |
|||
|
Hluav taws xob systems thiab teeb pom kev zoo |
teeb |
LED |
||
|
Qhov hluav taws xob |
24V |
|||
|
Txais |
7 txoj kev (7 hlau hlua) thiab hloov ceev hom thiab 15 txoj kev (15 hlau hlua) |
|||
Kev siv thiab qhov zoo:
Raws li ib yam ntawm cov van, sab curtain trailer muaj tag nrho cov yam ntxwv ntawm ib tug zoo tib yam van: lub hnab ntawv kaw kiag li, uas yuav tiv thaiv tau los nag thiab plua plav, thiab muaj peev xwm ua tau tag nrho cov huab cua tiv thaiv rau cov khoom; Lub ntim ntawm lub hnab ntawv tau txiav txim siab tag nrho, uas tuaj yeem tiv thaiv kom tsis txhob overloading thiab overrun. Vim tias cov ntaub thaiv sab nrauv raug kaw los ntawm cov ntaub thaiv ob sab, nws muaj qee qhov zoo dua ntxiv: vim tias sab kab hlau rhuav qhov hnyav yog qhov sib zog dua li lub vaj huam sib luag nyuaj, yog li tag nrho cov semi trailer yog sib dua li lub van; Sab kab hlau rhuav yog tiaj tus thiab haum rau luam tawm ntau yam qauv, yog li cov tsos zoo nkauj zoo nkauj dua li ntawm lub van; Cov ntaub thaiv tuaj yeem rub tau qhib sai, thiab lub forklift tuaj yeem thauj khoom thiab tshem tawm ntawm sab ntawm lub tsheb, yog li kev thauj khoom thiab kev thauj khoom tau zoo heev.
Cim npe nrov: high quality curtain semi trailer, Tuam Tshoj zoo nkauj semi trailer manufacturers, lwm tus neeg
