40ft Flatbed Truck Trailer
Peb 40ft flatbed tsheb trailer: Lub tsheb ciav hlau flatbed trailer no yog ib tus neeg muag khoom kub hauv Suav teb, rau kev thauj cov thawv hnyav hauv txoj kev phem. Nrog rau ntau tshaj 20 xyoo kev xa tawm, peb cov kev lag luam txawv teb chaws muaj ntau tshaj 40 lub teb chaws thiab cheeb tsam, xws li Southeast Asia, Africa, Middle East, South America, thiab lwm yam.
Khoom Taw qhia
Khoom taw qhia
40ft flatbed tsheb trailer yog siv los thauj cov thawv lossis cov khoom thauj khoom qhuav.
Main beams welded los ntawm advanced loj-scale tshwj xeeb vuam tshuab txiav.
Tongyada hom thiab CCC / ISO9001 daim ntawv pov thawj pom zoo.
Peb txais yuav cov khoom lag luam nto moo rau peb cov trailer, ua kom cov cim zoo.
Peb yog cov chaw tsim khoom hauv Suav teb los ntawm 1982, koj tuaj yeem kho koj tus kheej cov tsheb thauj khoom, peb tsim thiab tsim khoom raws li koj qhov kev xav tau.
Khoom piav qhia
Peb 40ft flatbed tsheb trailer: Lub tsheb ciav hlau flatbed trailer no yog ib tus neeg muag khoom kub hauv Suav teb, rau kev thauj cov thawv hnyav hauv txoj kev phem. Nrog rau ntau tshaj 20 xyoo kev xa tawm, peb cov kev lag luam txawv teb chaws muaj ntau tshaj 40 lub teb chaws thiab cheeb tsam, xws li cov teb chaws Asia, Africa, Middle East, South America, thiab lwm yam. Teeb tsa lub chaw tshawb fawb tom qab kws kho mob, koom tes hauv kev kos duab hauv teb chaws. thiab cov qauv kev lag luam, ua rau cov qauv tshiab ntawm kev tsim qauv, kev siv cov khoom siv raw, thiab cov khoom siv & cov khoom siv tes ua, tsim kev tsim kho tshiab, ib txwm raug coj los ua, tab sis tsis tau dhau. Ib txwm tsim nyob rau hauv lub tswv yim ntawm kev nyab xeeb, ua haujlwm tau zoo, kev tiv thaiv ib puag ncig, kev txawj ntse adaptability. thiab lwm yam. dav tswv hom ntawm txoj kev mob, hom kev thauj khoom, hom thauj ib puag ncig hauv tsev thiab txawv teb chaws, tsim nyog ua kom zoo dua cov qauv, muab cov khoom zoo thiab cov khoom tsim rau cov neeg siv khoom, tiag tiag embody peb cov khoom zoo. Tsim TONGYA cov kev pabcuam tshwj xeeb hauv siab, muab cov kev daws teeb meem rau cov neeg siv khoom, thiab xyuas kom zoo thiab tsim kom muaj txiaj ntsig ntau rau cov neeg siv khoom.
KhoomSpecification
|
Qauv |
40ft flatbed tsheb trailer |
|
Zuag qhia tag nrho |
12,500mm * 2,500mm * 1,550mm |
|
Tare luj |
7, 200 Kg |
|
Them nyiaj |
45,000kgs, peb tuaj yeem tsim raws li koj xav tau |
|
Kuv Beam & Chassis |
Heavy luag hauj lwm thiab ntxiv durability tsim kuv beam; Kev xaiv rau siab tensile steel Q345B, welded los ntawm cov txheej txheem tsis siv neeg Submerged-Arc. Sab saum toj Flange 16mm, dav 140mm; Middle Flange 8mm, Qhov siab 500mm, Hauv qab Flange 16mm, dav 140mm |
|
Qag |
Tongya hom, 13T / qag |
|
Tus naj npawb ntawm axles |
3ax ua |
|
Kev ncua |
Heavy duty mechanical suspension |
|
Pem teb |
3mm pob zeb diamond steel phaj |
|
King Pin |
JOST hom 2" Bolt-hauv King Pin |
|
tsaws iav |
JOST hom Ob-ceev, phau ntawv khiav hauj lwm, hnyav tsaws iav |
|
Log Rim |
9. 0-22.5, 13 daim |
|
Lub log |
12 R22.5, 13 pcs |
|
Spare Tyre |
2 units |
|
Twist Lock |
12 units |
|
Braking System |
WABCO RE 6 relay valve; T30/30 ntxiv rau T30 Caij nplooj ntoos hlav braking chambers; ob daim ntawm 45L cua tso tsheb hlau luam |
|
Kev pleev xim |
Ua kom tiav Chassis xuab zeb blasting los ntxuav xeb, 1 lub tsho tiv no ntawm anticorrosive prime, 2 lub tsho tiv no ntawm cov xim kawg |
|
Tool lub thawv |
Ib lub thawv khoom txheem (Qhov Loj tuaj yeem xaiv tau dawb) (nrog 1 lub log tsheb spanner, 1 unit gudgeon lub tes tsho thiab 1 unit cranking bar) |
Cim npe nrov: 40ft flatbed tsheb trailer, Tuam Tshoj 40ft flatbed tsheb trailer manufacturers, lwm tus neeg
