40ft Thawv Semi Trailer
Tuam Tshoj ua trailer chaw tsim tshuaj paus txij li thaum xyoo 1988, tuaj yeem muab ntau yam trailer rau koj !TONGYADA hom 40ft thawv semi trailer tuaj yeem kho.
Khoom Taw qhia
40ft thawv semi trailer yog kev thauj tshwj xeeb rau txhua yam ntim. Koj tuaj yeem siv nws los nqa ib lub thawv 40inch cargo, ob lub thawv 20inch, lossis 0ne 20inch thawv ib zaug.
Nws yog tsuas yog siv nyob rau hauv logistics systems txhawb nqa nkoj, chaw nres nkoj, txoj kev, txoj kev loj, hloov chaw, txuas hniav, tunnels, thiab multi-modal thauj.
Cias qhia peb yam khoom yuav tsum tau nqa, thiab peb yuav tsim ib lub thawv 40ft semi trailer raws li.
Specification rau Flatbed Semi Trailer | |
Chaw tsim tshuaj paus | Tongya Automobile CO., LTD. |
Hom | 40ft thawv semi trailer |
Tare luj | Kwv yees li. 6.2t ib |
Dimension | 12500 * 2500 * 1550mm |
Chaw thau khoom muaj peev xwm | 40t |
Qag | Fuwa |
Rim | 9.00*22.5 |
Lub log | 12.00R22.5 |
Kev ncua | Mechanical suspension |
Nplooj Caij nplooj ntoos hlav | 90 (dav) hli * 13 (thickness) hli * 10 txheej (tshwj xeeb rau kev lag luam xa tawm) |
King pin | TONGYADA |
Ncaws pob | TONGYADA |
Main beam | Q345B steel hlau |
Sab beam | 16 hli channel steel (Cov khoom yog Q235B steel) |
Hauv qab Platform | 3mm check steel phaj |
Nres chamber | Wabco re 6 relay valve; T30/30 ntxiv rau T30 caij nplooj ntoos hlav nres chamber; ob chav ntawm 45L cua tso tsheb hlau luam |
ABS | xaiv tau |
Valve | Wabco valve (tshwj xeeb rau kev lag luam xa tawm) |
Teeb | LED Teeb (tshwj xeeb rau kev lag luam xa tawm) |
Qhov hluav taws xob | 24V |
Txais | 7 txoj kev (7 hlau hlua) |
Tool lub thawv | Ib thooj 1m * 0.5m * 0.5m (qhov loj tuaj yeem kho tau) |
Kev pleev xim | 1 tus nqi ntawm anticorrosive primer, 2 lub tsho tiv no ntawm cov xim kawg, xim qhia los ntawm cov neeg siv khoom |
Cov nqe lus shipping | Los ntawm cov nkoj loj, RORO, lossis 40HQ thawv |
Txhua qhov chaw haum tuaj yeem ua raws li cov neeg siv khoom thov, tiv tauj peb kom tau txais ntau ntxiv. | |
TONGYADA hom 40ft thawv semi trailer, yog tsim los ntawm cov qauv hlau -Q345, thiab Q235. Lub nqaj nqaj yog vuam los ntawm vuam tshuab nrog Laser nrhiav thiab polished los ntawm kev txhaj tshuaj blasting tshuab, yog li qhov zoo yog guaranteed thaum pib. Rau kev xa tawm, peb siv cov khoom lag luam nto moo, xws li JOST hom kinpin thiab tsaws ceg, WBACO braking valve.
Tom qab 35 xyoo ntawm kev tshawb fawb thoob ntiaj teb kev lag luam, peb 40ft thawv semi trailer yog paub zoo thiab txais los ntawm peb cov neeg muas zaub los ntawm Afria, Midde sab hnub tuaj, South Asia, thiab South America.
Txoj cai zoo yog muab rau koj los koom nrog peb ua tus neeg muag khoom.
Koj yeej ib txwm txais tos tuaj xyuas peb lub tuam txhab thiab lub Hoobkas rau kev koom tes ua lag luam !!!
Cim npe nrov: 40ft thawv semi trailer, Suav teb, neeg muab khoom, manufacturers, customized, nqe
