Cov khib nyiab Compactor Truck
Lub tsheb thauj khoom khib nyiab yog lub thawv tshiab nkhaus compression khib nyiab tsheb pib los ntawm Tongya Hnyav Kev Lag Luam raws li Dongfeng National Sixth Class II chassis DFH1180EX8, ua ke nrog cov khoom siv thev naus laus zis Asmeskas thiab Nyij Pooj.
Khoom Taw qhia
Khoom taw qhia
Lub tsheb thauj khoom khib nyiab yog lub thawv tshiab nkhaus compression khib nyiab tsheb pib los ntawm Tongya Hnyav Kev Lag Luam raws li Dongfeng National Sixth Class II chassis DFH1180EX8, ua ke nrog cov khoom siv thev naus laus zis Asmeskas thiab Nyij Pooj.
Kev sau thiab hloov cov khib nyiab compactor tsheb yog ua tiav los ntawm kev thauj khoom tom qab compression thiab bidirectional compression tshuab, nrog lub peev xwm nqa tau zoo thiab muaj peev xwm thauj khoom loj. Nws yog qhov tsim nyog rau kev sau thiab kev thauj mus los ntawm cov khib nyiab hauv tsev hauv cov thoob, hnab ntim khoom thiab cov khoom loj hauv nroog thaj chaw, cov zej zog, cov lag luam loj, thiab cov nroog qub. Rau kev hloov mus, ntau txoj kev pub mis ntawm cov khib nyiab compactor tsheb tuaj yeem raug xaiv kom tau raws li qhov xav tau ntawm cov neeg siv sib txawv.
Khoom piav qhia
Cov khib nyiab compactor tsheb txais cov qauv tsim, uas yooj yim rau kev khaws cov dej phwj tuaj thiab khaws cia.
Kev kho txhua yam kev tiv thaiv corrosion: Lub thawv yog ua los ntawm cov ntaub ntawv muaj zog corrosion-resistant, thiab sab hauv yog txau nrog hnyav-tiv thaiv-corrosion xim. Tom qab electrophoresis thiab high-temperature ci xim kho.
Cov khib nyiab compactor tsheb muaj lub zog siab, muaj zog corrosion kuj thiab ntev kev pab cuam lub neej nyob rau hauv tib lub chaw ua hauj lwm. Nta: Cov khoom siv silicone uas muaj zog tiv thaiv corrosion yog siv rau kev kho sealing, uas tuaj yeem tiv thaiv kom tsis txhob muaj cov khib nyiab thiab dej phwj tuaj ntawm txoj kev thiab tiv thaiv cov pa phem thib ob.
Siv ob txoj kev siv tshuab compression, qhov sib piv compression tuaj yeem ncav cuag ntau dua 1: 2.5, thiab cov khib nyiab hauv tsev tuaj yeem ncav cuag ntau dua 600-800kg / m3.
Lub tsheb thauj khoom khib nyiab tau txais kev tsim arc nto thiab yog ua los ntawm lub zog siab manganese steel phaj, nrog cov phab ntsa du, tsis muaj pob txha, corrosion kuj, tsis muaj khib nyiab cia, ntim loj, thiab lub sijhawm ua haujlwm ntev.
Khoom Specification
Tsis muaj. | Hom Parameter | Yam khoom | Model thiab parameters |
1 | Chassis Parameters | Chassis qauv | Dongfeng Tianjin DFH1180EX8 |
2 | Cav qauv | D6.7NS6B230 | |
3 | Hom roj | Diesel | |
4 | Emission txheem | Tuam Tshoj tau tshaj tawm txoj xov zoo | |
5 | Lub cev muaj zog (kw) | 169 | |
6 | Log tsheb loj | 11.00R20 | |
7 | Qhov ceev tshaj plaws (km / h) | 89 | |
8 | Tus naj npawb ntawm cov neeg nyob hauv cab (tus neeg) | 3 | |
9 | Loj tsis muaj | Qhov hnyav tag nrho (kg) | 18000 |
10 | Qhov hnyav (kg) | 11250,11380 | |
11 | Rated load hnyav (kg) | 6555,6425 | |
12 | Dimensional parameters | Dimensions (ntev × dav × qhov siab) (mm) | 9005,8975×2500×3150 |
13 | Wheelbase (mm) | 4500 | |
14 | Pem hauv ntej suspension / rear ncua kev kawm ntawv (mm) | 1430/2735 | |
15 | Nkag mus / Tawm mus (degree) | 17/16 | |
16 | Cov cuab yeej tshwj xeeb tsis muaj | Qhov ntim tau zoo ntawm lub tsheb thauj khoom (M3) | 13 |
17 | Ntim ntim (M3) | 2 | |
18 | Lub sijhawm ntawm ib lub voj voog ua haujlwm ntawm kev thauj khoom (s) | Tsawg dua los yog sib npaug li 25 | |
19 | Lub sij hawm ntawm ib lub voj voog ua haujlwm ntawm kev thauj mus los (s) Tsawg dua lossis sib npaug li 25 (s) | Tsawg dua los yog sib npaug li 25 | |
20 | Tshem tawm lub kaum sab xis(degree) | Ntau dua lossis sib npaug li 50 | |
21 | Txoj kev ua haujlwm | Cab Pneumatic & External phau ntawv |
